Performance

• Temperature range from ambient +5°C to 250°C
• Vacuum range: 0 to 0.1 MPa. (analog vacuum gauge)
  - Drying a solvent in vacuum lowers its boiling point, thereby making the separation process easier and eliminating the need to use high temperatures.
• Microprocessor PID control / Temperature calibration / Automatic tuning.
• Uniform heat distribution from block type heater attached to the chamber exterior to the anodised aluminium shelves.

Convenience

• Intuitive control panel with bright LED displays. (1°C resolution)
• Dual wait on/off timer modes. (1 min. to 99 hr. 59 min.)
• Convenient presetting function for 3 most commonly used temperature settings.
• Viton (fluorine rubber) door gasket also available for acidic applications. (optional)
• Heat tempered glass window provides clear inside view of the chambers
• Tight vacuum seal thanks to spring-loaded glass door, silicone gasket, and a push-button latch handle.
• Separate vacuum and vent ports.
• RS-232 interface for external control and data collection.

Safety

• Keypad lock function prevents accidental changes during operation.
• Automatic run after power interruption.
• Over-temperature and over-current protection.

For more information, visit JeioTech.com.
